Mindray BeneHeart D3 Defibrillator Main Board Mother Board
Mindray BeneHeart D3 Defibrillator Main Board Mother Board Defibrillator Parts 115-007254-00
► Brief Introduction
Mindray BeneHeart D3 defibrillator offers four operating modes: Defib, AED, Pacer and Monitor. Mindray BeneHeart D3 defibrillator for use in hospitals and pre-hospital. It adopts the most advanced biPHiliphhilipasic defibrillation techniques and can provide up to 360 joules of defibrillator energy.
► Mindray BeneHeart D3 defibrillator function
Asynchronous defibrillation mode for ventricular fibrillation orthodontic arrhythmia evaluation. Simultaneous defibrillation mode for atrial fibrillation orthotic arrhythmia evaluation.
In AED mode, BeneHeart D3 automatically analyzes the rhythm and determines whether the shock is necessary. Audio and text claims guide the user during the process. Audio recording (180 minutes) is also available for post-case analysis and review.
Diagnostic quality, 3/5 ECG monitoring with breathing, NIBP, SpO2 and EtCO2.
Mindray BeneHeart D3 defibrillator provides external dial and fixed mode speed with adjustable rates and output. Key 4:1 enables doctors to choose a 1/4 pacer rate quickly set to monitor the patient's basic rhythm.
► Removing the Main Board Assembly
1. Disconnect the cable between the main board and keypad board.
2. Unscrew the seven M3×8 PHiliphhilip screws, and then remove the M4×20 bolt.
If you only need to remove the main board and CF data card, unscrew the four M3×6 PHiliphhilip screws securing the main board
3. Pull out the cable connecting the power management board and AC/DC power supply board from the rear housing. Remove the main board assembly
4. Remove the two M3×6 PHiliphhilip screws. Take out the capacitor bracket and then the capacitor.
► Main Board Assembly
| 1 | 0652 Power management board PCBA (FRU) |
| 2 | Holder-plug |
| 3 | Stud screw, M3×7+8-6 |
| 4 | Storage Card, |
| 5 | PHiliphhilip screw, M3×6 |
| 6 | Main board (FRU) |
| 7 | PCB fixed bosses |
| 8 | Stainless steel nut, GB6170 M4 |
| 9 | Stainless steel nut, GB6170 M3 |
| 10 | Output interface seal pad |
► Other Business
In addition to engaging in medical devices, accessories and repair parts sales business, we also specialize in repairing that kind of machines and modules. Since we are proficient in hospital equipments maintenance technology, we are skilled in refurbishing damaged machines and accessories. Therefore, if you have this kind of machines or modules for repair, you can contact us and sent us, we will get them repaired at the fastest speed. But it is worth noting that you must ensure the item that need repair is unopened and has never been repaired before. Otherwise it is unacceptable to us. In conclusion, please kindly check your item carefully before send it out.
Please kindly contact us, if you are interested in Mindray BeneHeart D3 Defibrillator Main Board Mother Board Defibrillator Parts 115-007254-00, Thank you!
